Home /Products/Public Toilet Partition/Service Station Toilet Partition | HPL Compact Laminate Public Restroom Cubicle

Service Station Toilet Partition | HPL Compact Laminate Public Restroom Cubicle

45 square
MOQ
70 to 200 dollars
Price
Service Station Toilet Partition | HPL Compact Laminate Public Restroom Cubicle
Features Gallery Product Description Chat Now
Features
Specifications
Material: Public Toilet Partition / HPL Compact Laminate Restroom Cubicle
Surface: Matte / Texture
Color: Customizable
Waterproof: Yes
Wear Resistance: High
Hardware: Stainless Steel / Nylon
Highlight:

HPL compact laminate toilet partition

,

public restroom toilet cubicle

,

service station toilet partition
Basic Infomation
Place of Origin: China
Brand Name: Remeijia
Model Number: GQ0936
Payment & Shipping Terms
Packaging Details: Wooden Support Plate Packaging
Delivery Time: Ships in about fifteen days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 50,000 square meters per month
Product Description

Our HPL compact laminate toilet partitions are engineered specifically for highway service stations, rest stops, and other high-traffic public restroom environments. Built to withstand constant use, frequent cleaning, and high humidity, these phenolic board toilet cubicles deliver long-lasting durability while maintaining a clean, modern appearance.
Designed for commercial restrooms that see hundreds or thousands of visitors daily, our service station toilet partitions combine waterproof solid-core phenolic panels with heavy-duty stainless steel hardware to resist wear, moisture damage, and vandalism.

Key Product Features

1. Waterproof HPL Compact Laminate Panels

  • Material: High-pressure laminate (HPL) phenolic board, solid-core construction
  • Thickness options: 12mm / 15mm / 18mm
  • Water resistance: Fully impervious to water, steam, and humidity — will not swell, delaminate, or warp when exposed to moisture
  • Surface finish: Matte, scratch-resistant, stain-resistant
  • Color-through core: Edge chips and minor scratches are far less visible than with surface-laminated alternatives
  • Easy to clean: Smooth non-porous surface resists graffiti, ink, and soap scum — wipes clean with standard commercial cleaners

2. Heavy-Duty Stainless Steel Hardware

  • Posts & feet: 304-grade brushed stainless steel floor pedestals with adjustable levelers [需确认材质等级]
  • Hinges: Heavy-duty self-closing stainless steel hinges, designed for millions of open-close cycles
  • Door handles: Brushed stainless steel pull handles with smooth grip
  • Privacy locks: Occupant indicator locks — red/white display shows whether a stall is occupied
  • Corrosion resistance: Stainless steel resists rust and corrosion even in damp restroom environments
  • Child-safe: Rounded edges and smooth surfaces minimize injury risk

3. Smart Modular Design

  • Floor-standing installation: Stainless steel floor pedestals raise panels off the floor, simplifying mopping and floor cleaning
  • Top clearance: Open gap above panels improves ventilation and makes ceiling cleaning/maintenance easier
  • Adjustable feet: Leveling pedestals adapt to uneven service station floors
  • Modular layout: Flexible configurations — single stalls, multi-stall banks, or row setups to fit your restroom dimensions
  • Quick assembly: Pre-drilled panels and standardized hardware reduce installation time on site

4. Commercial-Grade Durability

  • Impact resistance: Solid phenolic core withstands bumps, kicks, and heavy daily use
  • Scratch resistance: Surface stands up to backpacks, luggage, and cleaning equipment
  • Stain resistance: Coffee, soda, soap, and other common spills wipe off easily without staining
  • Vandalism resistance: Difficult to damage, write on, or pry apart — ideal for unattended public restrooms
  • Long service life: Designed for 10+ years of reliable performance in high-traffic commercial restrooms

Technical Specifications

Parameter
Details
Notes
Panel Material
HPL Compact Laminate (Phenolic Board)
Solid core, color-through
Panel Thickness
12mm / 13mm / 18mm available
Standard: 12mm
Standard Door Width
900mm (35.4")
Custom widths available
Standard Door Height
1900mm (74.8")
Custom heights available
Overall Height
2000mm - 2100mm (79" - 83")
Includes floor pedestal
Hardware Material
Stainless Steel (304 grade)
Brushed finish standard
Installation Type
Floor-standing with stainless pedestals
Ceiling-hung also available
Standard Color
Dark gray matte finish
20+ color options available
Edge Banding
Black PVC edge banding / matching edge
Smooth, sealed edges

Application Scenarios

Highway Service Stations & Rest Areas

Built for the busiest rest stops on the road — handles thousands of daily visitors, frequent deep cleaning, and constant moisture from handwashing and mopping.

Truck Stops & Gas Station Restrooms

Heavy-duty construction stands up to professional drivers, luggage, and high-volume use around the clock.

Shopping Malls & Public Facilities

Clean, uniform appearance complements modern public architecture while withstanding family foot traffic.

Airports & Bus Stations

Reliable performance in continuous-operation environments where downtime and maintenance are costly.

Stadiums, Parks & Recreation Areas

Withstands seasonal peak demand and outdoor-adjacent humidity without deterioration.

Why Choose Our Service Station Toilet Partitions?

Built for High Traffic
Tested and proven in service stations that handle tens of thousands of visitors per month. Every component — from panel core to hinge hardware — is specified for commercial, high-cycle use.
Fully Waterproof
Solid phenolic core means no swelling, no delamination, no mold growth. Wipe down restrooms as often as needed — the partitions will hold up.

Customizable Solutions
Standard sizes ship quickly; custom dimensions, colors, and configurations available for renovation or new build projects. Tell us your room layout and we'll provide a layout proposal.
Export Packaging
Panels flat-packed in export-grade cardboard and wooden crates, suitable for sea freight. Clear labeling and packing list make on-site inventory check easy.

What's Included in a Standard Order

  • HPL compact laminate door panels and side/end panels
  • Stainless steel posts, floor feet/pedestals
  • Stainless steel hinges, door handles, and privacy locks
  • All necessary mounting screws and fasteners
  • Edge banding and trim pieces
  • Installation manual / assembly guide
